Important Notes
- Will not work on TRD ProModels
- Minor weldingrequired
- Requires frame bracketmodification
- Stock wheels cannot bereinstalled
- System will work on 2WDPreRunner models
- Kit requires 18"or larger wheels,17" wheelscannot be used.
Features
- FOX 2.5 PerformanceElite series coilovers andchoice of FOX 2.0 or 2.5(PE) rear shocks forimproved ride quality,performance, andcapability
- High clearancecrossmember designmaximizes groundclearance
- Robust steering knucklesmaintain ESC systemcompliance
- HD skid plate system improvedoffroad protection
- Multipointdifferentialrelocation bracketsto secure the frontaxle and improveCV angles
- Factory ProtectionPlus drivetrainwarranty included
Manufacturer's Description
Get the ultimate look and performance for your Toyota Tacoma with the BDS 6-inch suspension lift kit featuring FOX 2.5 Performance Elite (PE) coil-overs and shocks. These kits feature the newaluminum-bodied FOX 2.5 Performance Elite (PE) coil-over shocks designed specifically to bolt-on performance for increased travel, more adjustability via DSC adjustment, and better heatdispersion allowing you to soak up the roughest terrain on and off-road. Designed to improve stance, performance, and capability, BDS includes everything necessary to set your truck up right withclearance for up to 35" tires.This kit takes advantage of BDS's tried and true high-clearance design for improved ground clearance, strength, and offroad protection while correcting suspension and steering geometry for greaton-road handling characteristics. Up front, this kit pairs the FOX 2.5 PE Coil-Overs with high-arched 1/4-inch thick steel crossmembers along with a multipiece differential relocation brackets andheavy duty skid plates built for offroad protection. Steering geometry is corrected at the new taller ride height with CNC-machined ductile iron steering knuckles utilizing factory tie rod ends allowingfor ESC system compatibility. These combined with the provided sway bar drops, bump stop extensions, brake line brackets, lower control arm cams, FOX reservoir mounts and supplied hardwarepacks provide a comprehensive front suspension lift ready for whatever you throw at it.In the rear, this kit utilizes heavy duty cast steel lift blocks, brake line bracket and longer u-bolts to lift and level the stance without effecting load capacity. For shocks you have the option of FOX 2.0IFP performance series gas shocks or upgrade to the FOX 2.5 Performance Elite (PE) series remote reservoir shocks to match the front and further enhance vehicle performance and adjustability.
FOX 2.5 PE Coil-Overs
FOX 2.5 Performance Elite (PE) coil-overs offer next level performance for on-road comfort and off-road comfort capability. Tuned and ready to install right out of the box, these aluminum bodiedFOX 2.5-inch diameter coil-overs are the latest iteration of FOX suspension technology built for abuse. Lighter design, better heat dispersion, and race-proven components for the best all aroundproduct. These include DSC (Dual Speed Compression) adjusters on the remote reservoir for additional fluid capacity and high-speed/low-speed compression tuning to easily dial in performance tomatch any terrain with the turn of the knobs.
HD Components
All BDS kits come with a No Fine Print Warranty and to ensure our kits are the best they can be we use high-strength American steel, high clearance and fully welded crossmembers, the latestmanufacturing processes and quality inspection every step of the way. Get the most out of your truck with BDS Suspension and FOX.
Options
Rear Shock Option
FOX 2.0 Performance Series
- 2-inch Impact extruded aluminum body
- Internal floating piston (IFP) monotube design
- CNC machined 6061-T6 aluminum mounting ends
- Large 5/8-inch hard chrome plated heat-treated alloy steel shaft
- Race-developed high-flow piston design
- Application-specific valving to maximize performance
- Long-lasting clear anodized finish
FOX 2.5 Performance Elite Series
- Increased off-road capabilities
- Easily adjust your shock for terrain, load and speed
- 2.5-inch Impact extruded aluminum body
- Massive 7/8-inch hard chrome plated heat-treated alloy steel shaft
- External reservoir design separates shock oil from the high-pressure nitrogen
- DSC - Dual Speed Compression Adjuster comes standard
- Fully serviceable for a lifetime of use
- 1-year Manufacturer's Warranty
