BDS 6 Inch Lift Kit | Ram 3500 (13-18) 4WD | Diesel

BDS 6 Inch Lift Kit | Ram 3500 (13-18) 4WD | Diesel

BDS Suspension

BDS 6 Inch Lift Kit | Ram 3500 (13-18) 4WD | Diesel

Name: BDS 6 Inch Lift Kit | Ram 3500 (13-18) 4WD | Diesel
Brand: BDS Suspension
SKU: BDS1788H
Price: 1754.7 USD
Availability: InStock

SKU: BDS1788H

UPC: 840416412604

Condition: New

$1,754.70

Rear Lift Option: *

Indexing Ring Option: *

Shock Option: *

Current Stock:

Quantity:

Free Shipping to Continental US

Product Details
Shipping & Returns
Fitment

Product Details

Important Notes

The carrier bearing drop is necessary for models equipped with the two-piece rear drive shaft.
Dually with 8-bolt Transmission (Aisin), require BDS122409 Def Relocation Kit
Mega Cabs with 8-bolt Transmission (Aisin), require BDS122409 Def Relocation Kit
Vehicles equipped with a Manual T-case requires BDS122423 Manual transfer case shifter extension
Vehicles equipped with a 2-piece rear drive shaft (carrier bearing), require BDS122406 Carrier bearing drop.
Some vehicles may require a rear driveshaft spacer kit 122007 to maintain adequate rear driveshaft engagement.

Features

Heavy duty radius arm drop brackets maintain proper suspension geometry
Front high strength progressive rate coil springs for a great ride on any terrain
Front track bar relocation bracket to re-position axle
Forged drop pitman arm to correct steering angles
Front sway bar correction to maintain handling performance
HD transmission crossmember and t-case indexing ring to correct front driveline angles and allow use of factory driveshafts
BDS NX2 gas or FOX performance series IFP gas shocks to improved ride and offroad performance

Manufacturer's Description

Improve the ride and style of your 2013-2018 RAM 3500 diesel powered truck with this 6-inch lift kit from BDS Suspension. Designed to improve stance, performance, and capability, this kit includes everything necessary to set your truck up right with clearance for up to 37" tires.

Up front the lift kit includes diesel-specific Pro-Ride coil springs, radius arms drop brackets, forged drop pitman arm and track bar bracket for steering correction, bump stops, brake line brackets and precision tuned NX2 or FOX 2.0 nitrogen charged shocks.

In the rear this kit utilizes a high-strength fabricated lift block, longer u-bolts and a matching set of NX2 Nitro or FOX 2.0 Performance shocks.

Pro-Ride Coil Springs

A pair of full-length, diesel-specific, progressive rate Pro-Ride coil springs are supplied to provide the correct lift height and smooth, predictable ride across various terrains.

Steering Correction

To optimize steering geometry once lifted, a forged drop pitman arm is used to minimize the steering angle and pair it with a heavy duty track bar drop bracket to keep them in phase through suspension travel while recentering the front axle.

Shipping & Returns

Fitment

Product Specs

SKU: BDS1788H

UPC: 840416412604

Condition: New

Front Lift Height: 6

Front Lift Method: Coil Spring

Rear Lift Height:

4.5"

4 5"

Rear Lift Method:

Leaf Spring

Block

Recommended Tires & Wheels:

37 x 13.5 with 17 x 9 and 5.625 in. Backspace

37 x 12.5 with 18 x 9 and 4.5 in. Backspace <li>37 x 13.5 with 17 x 9 and 5.625 in. backspace</li> <li>37 x 12.5 with 18 x 9 and 4.5 in. backspace</li> <li>37 x 12.5 with 20 x 9 and 4.5 in. backspace</li>

Shocks Included: Yes

Part Type: Suspension Lift Kit

Installation Details

Installation Time 6-8 hrs

Installation Difficulty Moderate

Installation Tools Step Drill Bit, Drill / Bit Set, Pitman Arm Puller, Welding Equipment

Downloads

Installation Instructions
