Zone Offroad
Zone 4 Inch Lift Kit W/ Radius Arm | Ram 2500 (14-18) 4WD | Gas
SKU:
ZOND63N
UPC:
810156368189
Condition:
New
$1,246.50
Free Shipping to Continental US
Important Notes
- Although very rare, front driveline vibration may occur at speeds over 35 mph when in 4WD. If this occurs, install the appropriate optional t-case indexing kit.
- Optional t-case indexing ring kit recommended to reduce front driveline angle.
- Fits 6.4L Gas Engine Models.
- Does NOT work for models with factory rear airbag suspension.
- Two-piece rear drive shaft? Add a carrier bearing drop kit to reduce post-lift driveline angles and avoid / eliminate driveshaft vibration.
- Will not fit Power Wagon models.
- 6.4L Gas models will require exhaust modification to clear the front driveshaft. 5.7L Gas models may require modification
Features
- Progressive rate front coil springs improve ride quality and off-road performance.
- HD radius arm to correct caster while maximizing ground clearance.
- Forged pitman arm and track bar relocation bracket to correct steering angles and recenter front axle.
- Extended bump stops, sway bar relocation and brake line relocation to maintain factory-like operating angles.
- Rear coil spacers, bump stop extensions, track bar bracket and sway bar links to level the stance and correct suspension geometry
Manufacturer's Description
Take your RAM 2500 to new heights with this 4" lift kit from Zone Offroad. Kits include everything needed from full length coil springs and stout radius arms to steering correction and rear lift to level the stance. Get the look, performance, and capability your truck deserves with clearance for up to 37" tires.
Options
Shock Option
Nitro Series
- Nitrogen-charged
- Twin-tube design
- 10-stage velocity-sensitive valving
- Dual-welded ends for increased strength
- Self-lubricating seals
- Black powder coat finish
FOX 2.0 Adventure Series
- 2-inch diameter steel body
- Internal floating piston (IFP) monotube design
- Large 5/8-inch hard chrome plated heat-treated alloy steel shaft
- Race-developed high-flow piston design
- Application-specific valving to maximize performance
- Long-lasting silver coated finish
Product Specs
SKU:
ZOND63N
UPC:
810156368189
Condition:
New
Front Lift Height:
4"
Front Lift Method:
Coil Spring & Drop Bracket
Rear Lift Height:
2.5"
Rear Lift Method:
Coil Spacer
Recommended Tires & Wheels:
35 x 12.5 with 17 x 9 and 4.5 in. Backspace
37 x 12.5 with 17 x 9 and 5.75 in. Backspace <li>35 x 12.5 with 17 x 9 and 4.5 in. backspace</li> <li>37 x 12.5 with 17 x 9 and 5.75 in. backspace</li> <li>37 x 12.5 with 20 x 9 and 5.75 in. backspace</li>
Shocks Included:
Yes
Part Type:
Suspension Lift Kit
Variant Position:
1
Installation Details
Installation Time
6 hrs
Installation Difficulty
Moderate
