Zone Offroad

Zone 6 Inch Lift Kit | Chevy/GMC 1/2 Ton Truck/SUV (88-98) 4WD

SKU: ZONC14N
UPC: 810156360121
Condition: New
$1,203.60

Free Shipping to Continental US

Important Notes

  • Auto-trac/Front Driveshaft? Models equipped with an auto-trac transfer case may require a new front driveshaft. Auto-trac transfer cases can be identified by a badge on the rear case that reads “NP246”. In addition, the dash mounted display will show the Auto 4WD symbol. Cases with “NP243” are not auto-trac.
  • Requires exhaust modification to clear the front driveshaft. See installation instructions for more information.
  • Not recommended for Tahoe/Yukon 4 door models.
  • Does NOT fit 8 lug models.

Features

  • Heavy-duty differential skid slate improves off-road protection.
  • High-strength, 1/4" steel construction crossmembers correct lower control arm geometry.
  • Lift system does not change the front track width of the vehicle.
  • Multi-point differential relocation brackets secure front differential for improved CV operating angles.
  • Relocation bracket allows for reinstallation of the factory spare tire.
  • Upper control arm relocation brackets correct front suspension geometry.

Manufacturer's Description

Turn heads and drop jaws when you lift your Chevy with this 6" Lift Kit. This kit has everything you need to clear 35" tires and all the pieces and parts for optimal steering and drivetrain geometry. Fits 4WD 1988 - 1998 Chevy/GM 6 lug K1500 and K2500 truck & SUVs.

Options

Shock Option

Nitro Series

  • Nitrogen-charged
  • Twin-tube design
  • 10-stage velocity-sensitive valving
  • Dual-welded ends for increased strength
  • Self-lubricating seals
  • Black powder coat finish

    Product Specs

    SKU: ZONC14N
    UPC: 810156360121
    Condition: New
    Front Lift Height: 6
    Front Lift Method: Cross Member & Torsion Drop
    Rear Lift Height: 5"
    Rear Lift Method: Block
    Recommended Tires & Wheels:

    35 x 12.5 with stock

    35 x 12.5 with 17 x 9 and 6 in. Backspace <li>35 x 12.5 with stock and Stock in. backspace</li> <li>35 x 12.5 with 17 x 9 and 6 in. backspace</li> <li>35 x 12.5 with 20 x 9 and 6 in. backspace</li>
    Shocks Included: Yes
    Part Type: Suspension Lift Kit
    Variant Position: 1

    Installation Details

    Installation Time 8 hrs
    Installation Difficulty Difficult
    Installation Tools Torsion Bar Unloading Tool
