Zone Offroad
Zone 6 Inch Lift Kit | Chevy/GMC Avalanche, Suburban, Tahoe, Or Yukon 1500 (99-06) 4WD
SKU:
ZONC7N
UPC:
810156369995
Condition:
New
$1,752.65
Free Shipping to Continental US

Important Notes
- Does NOT work with all wheel drive (AWD) models.
- Will not fit vehicles equipped with Auto-Ride.
- Use a 1/4" wheel spacer to accommodate factory 20" wheels; refer to the provided "Max Tire Size" for 20" wheels for tire sizing.
- Stock tires & wheels can be installed back on the vehicle, but larger tires can NOT be installed on factory wheels.
- Always check for wheel and tire clearance before driving the vehicle.
Features
- Heavy-duty differential skid slate improves off-road protection.
- High-strength, 1/4" steel construction crossmembers correct lower control arm geometry.
- High-strength, CNC machined, replacement Steering Knuckles improve strength while correcting steering angles.
- Multi-point differential relocation brackets secure front differential for improved CV operating angles.
Manufacturer's Description
When you go big you can go anywhere. This 6" Lift Kit puts your SUV into a class of its own, letting you clear 35" tires. Built for everyday driving but sturdy enough for off-road abuse. Get the look and performance you want out of your 4WD 2000 - 2006 Chevy/GM 1500 SUV.
Options
Shock Option
Nitro Series
- Nitrogen-charged
- Twin-tube design
- 10-stage velocity-sensitive valving
- Dual-welded ends for increased strength
- Self-lubricating seals
- Black powder coat finish
FOX 2.0 Adventure Series
- 2-inch diameter steel body
- Internal floating piston (IFP) monotube design
- Large 5/8-inch hard chrome plated heat-treated alloy steel shaft
- Race-developed high-flow piston design
- Application-specific valving to maximize performance
- Long-lasting silver coated finish
Product Specs
SKU:
ZONC7N
UPC:
810156369995
Condition:
New
Front Lift Height:
6
Front Lift Method:
Cross Member & Torsion Drop
Rear Lift Height:
5.25''
Rear Lift Method:
Coil Spring
Recommended Tires & Wheels:
33 x 12.5 with 17 x 9 and 4.5 in. Backspace
34 x 12.5 with 18 x 9 and 5 in. Backspace <li>33 x 12.5 with 17 x 9 and 4.5 in. backspace</li> <li>34 x 12.5 with 18 x 9 and 5 in. backspace</li> <li>35 x 12.5 with 20 x 9 and 5.75 in. backspace</li>
Shocks Included:
Yes
Part Type:
Suspension Lift Kit
Variant Position:
1
Installation Details
Installation Time
8 hrs
Installation Difficulty
Moderate
Installation Tools
Torsion Bar Unloading Tool
